Plastic Processing Machinery and Equipment for Converters and Recyclers
Flake and Powder dosing
MCHigh Output: accurate dosing of high capacities 50kg/hr to 1200kg/hr
MCHigh Output: accurate dosing of high capacities 50kg/hr to 1200kg/hr
MCHigh Output: accurate dosing of high capacities 50kg/hr to 1200kg/hr
The MCHigh Output is the gravimetric answer for dosing high capacities from 50 kg/h up to a maximum of 1,200 kg/h. The system doses this high output of additive without making any concessions to accuracy. The gravimetric technology makes this possible for both injection molding and extrusion applications.
The unit has an integrated weighing module that precisely measures the throughput by the lossin-weight principle. The fully gravimetric system continually calibrates the dosage and adjusts automatically. The refilling of the MCHigh Output is controlled by an integrated pneumatic operated knife valve at the top flange.
The MCHigh Output handles granulates, difficult regrinds and free-flowing powders. It is capable of processing hot materials up to 180°C.
“The MCHigh Output is perfectly capable of dosing our dried PET flakes that reach up to 180 °C”
Features MCHigh Output
- Full gravimetric control
- Easy to clean: the motor/screw assembly can be removed without tools
- Can handle granulates, difficult regrinds and free-flowing powders
- Equipped with an integrated slide valve to control the material loading
- Can handle hot materials up to 180°C
- Industry 4.0 ready
Benefits MCHigh Output
- Wide capacity range
- Multi material dosing
- Easy integration
- Gravimetric or volumetri
MCHigh Output 2500R: high capacity low bulk density dosing
MCHigh Output: accurate dosing of high capacities 50kg/hr to 1200kg/hr
MCHigh Output: accurate dosing of high capacities 50kg/hr to 1200kg/hr
The MCHigh Output 2500R is a complete system for feeding low density regrind at high dosing rates. The unique design with a mixing rate of maximum 75% can be mounted directly on top of the injection molding machine or extruder. The gravimetric technology controls the dosing rate and provides exact material consumption data for track and trace purposes.
The unit has an integrated weighing module that precisely measures the throughput by the loss-in-weight principle. Refilling of the hopper can be done either by direct mounting of the hopper-loader on top of the system or by the integrated knife valve at the top flange. The refilling is controlled by the gravimetric system.
The MCHigh Output 2500R handles granulates and difficult regrinds like PET bottle flakes. It is capable of processing materials up to 180°C.
The water-cooled neckpiece with integrated mixer ensures the right mixture of materials for your product and the possibility to add additional dosing stations for masterbatch or other additives.
Features MCHigh Output 2500R
- Fully gravimetric control
- Can handle low bulk density regrinds
- Direct mount loader option
- Magnet bars for separating metal parts
- Water-cooled neckpiece with integrated mixer
- Industry 4.0 ready
Benefits MCHigh Output 2500R
- High mixing rate
- Direct mounting
- Easy integration
MCPowder: trouble free dosing of non-free-flowing powders
MCPowder High Output: trouble free dosing of heavy duty powders
MCPowder High Output: trouble free dosing of heavy duty powders
The MCPowder addresses one of the most difficult challenges in the field of dosing powder, especially when we talk about non-free-flowing powders at extreme low rates. Expensive powder additives that add high impact to your process require the best in the field of accuracy and reliability.
Movacolor has, based on its proven gravimetric technology, developed a compact powder dosing unit to do just that. It doses as low as 100 g/h, but also as high as 40 kg/h. Double spiral and hopper agitation ensure trouble free dosing of the most difficult powders. And this is accomplished in both injection molding and extrusion applications.
The unit operates as a single unit, but can also be integrated into our unique modular continuous blending system, allowing to add the most difficult powders to the blend of your extruder. The MCPowder is a truly unique product in the market that makes you forget any powder dosing problem you currently might have.
Features MCPowder
- Double spiral/auger design for reliable dosing of non-free-flowing powders
- Agitator avoiding material clogging or rat holing
- High grade polished hopper
- Quick release coupling for easy cleaning
- Capacity 0,1 - 40 kg/hr
- Special support frame for hopper loaders available
- Ready for Industry 4.0
Benefits MCPowder
- Extremely accurate and robust
- User-friendly
- Modular
- Gravimetric or volumetric
MCPowder High Output: trouble free dosing of heavy duty powders
MCPowder High Output: trouble free dosing of heavy duty powders
MCPowder High Output: trouble free dosing of heavy duty powders
The MCPowder High Output stands up to the challenge of dosing powder. For your process stability and quality control an accurate and reliable powder dosing unit is often essential. And this under all circumstances.
Movacolor has, based on its proven gravimetric technology, developed a heavy duty powder dosing unit capable to dose maximum 450 kg/h of non-free flowing powder. The design is based on a single spiral and agitator, driven by a heavy duty 3 phase motor. The hopper can be increased in a modular way from 25 to 50 liters.
The unit is installed on two heavy duty load cells. Operation is done via our standard 8” full color touch screen. The unit operates as a single unit, but can also be integrated into our unique modular continuous blending system, allowing to add the most difficult powders to the blend of your extruder.
Features MCPowder High Output
- Single spiral design for reliable dosing of
non-free-flowing powders - Agitator avoiding material clogging or rat holing
- High grade polished hopper
- Two heavy duty load cells
- Modular hopper design
- Industry 4.0 ready
Benefits MCPowder High Output
- Acurate and robust
- User-friendly
- Modular
gravimetric Continuous blending
MCWeight: self-regulating material measuring system for extruders
MCWeight P: measuring actual feed capacity of an extruder consuming powder
MCWeight P: measuring actual feed capacity of an extruder consuming powder
The MCWeight is specially designed to measure the actual feed capacity of an extruder. It has an integrated weighing module to accurately measure throughput and an integrated knife valve to control the filling.
Combined with one or more Movacolor units, the MCWeight tracks even the smallest capacity variation of the extruder. It adjusts the additive dosing from the dosing units accordingly.
Dried material with a temperature up to 180°C can be handled with the MCWeight.
This throughput measurement system enables you to get the best out of your extrusion line. It gives you real time insight into your actual line capacity and tracks the consumption of your materials. In combination with our MCLine Control it can even control your complete extrusion line including upstream and downstream equipment.
Features MCWeight
- For granulates, regrinds and free-flowing powders
- Continuous loss-in-weight measuring
- Fast response to capacity changes
- Automatic filling through an integrated, pneumatic knife gate in top flange
- Control via 8” full color touch screen
- Available in 100, 500 or 1,200 kg/h
- Industry 4.0 ready
Benefits MCWeight
- Plug and play
The MCWeight can be connected to up to 14 Movacolor dosing units. No interface control with the extruder is required. Per co-extruder you can install an MCWeight that allows the controlling of multiple MCWeight units with one control interface. - Quality control
Quality is controlled by continually monitoring data from both the MCWeight and the dosing units. The MCSmart program gives you this maximum control. With the MCLine Control you can even fully control the extrusion line. - Basis for full control of your extrusion line
The MCWeight is the perfect basis for your MCContinuous Blender or for your MCLine Control system
MCWeight P: measuring actual feed capacity of an extruder consuming powder
MCWeight P: measuring actual feed capacity of an extruder consuming powder
MCWeight P: measuring actual feed capacity of an extruder consuming powder
The MCWeight P is designed for measuring pourable powders like PVC dry blend. The MCWeight P can also be applied for granular materials or pourable regrinds that contain dust. The construction of the pneumatic knife gate is dust tight. The manchets are dust tight and there are additional dust filters to handle powder.
The MCWeight P, like the MCWeight, is designed to measure the actual feed capacity of the extruder, save expensive additives and ensure high quality end product in extrusion production.
The MCWeight P measures the throughput of the main material and provides the exact throughput/output of your extruder within seconds of start up. Combined with up to to six MCBalance dosing systems, the MCWeight tracks the smallest capacity variation of the extruder. The additive dosing from the MCBalance(s) adjusts accordingly. The MCWeight P for powder comes in 500 kg/h and 1000 kg/h versions.
Features MCWeight P
- Continuous loss-in-weight measuring
- Automatic filling through an integrated, pneumatic knife gate in top flange
- Communication TCP/IP or Modbus
- Menu guided control and graphic, LCD display with backlight
- Capacity from 3 kg/h up to 1000 kg/h depending on the material
- Industry 4.0 ready
Benefits MCWeight P
- More control over the production process
- Prevents overdosing
- Quick color changes that can be performed during operation without interrupting the production process
- Robust design and very easy to clean
- Plug and play
MCContinuous Blender: unique modular in-line blender system
MCHybrid 200: the best of dosing and blending in one system with real time throughput measurement
MCHybrid 200: the best of dosing and blending in one system with real time throughput measurement
Advanced blending systems are often seen as complete plant engineered solutions. Movacolor has developed a unique modular system that allows you to put together a full gravimetric continuous blending system. Up to 15 components can be controlled from one controller. These systems can be installed on one extruder or on multiple co-extruders, creating a control platform for multiple continuous blenders in one system.
The system grows with your future needs. New components can easily be integrated without changes to the controller.
The MCContinuous Blender covers most of the available materials like granulates, regrinds, powders and liquids. All this in one system, with one standard controller and integrated loader control.
All the benefits of a continuous blender are suddenly within your reach. Our experience with in-line gravimetric dosing helps you to achieve the required accuracy for all your components, directly on the extruder.
Features MCContinuous Blender
- Capacities up to 2,000 kg/h. Fully gravimetric
- Modular system: granulates, regrinds, powders and liquids
- Handles up to 15 components
- Multiple continuous blenders on one standard controller
- High accuracy and direct response to recipe change
- Integrated loader control
- Can be extended or modified easily for future needs
- Industry 4.0 ready
Benefits MCContinuous Blender
- Modular control system
The 8” full color touch screen controller can control up to 15 components on either one extruder or divided over several co-extruders. Standard software can be configured on the spot and systems can be expanded without additional controller changes. - Different materials handled
All standard Movacolor gravimetric units can be integrated into one blending system, able to dose granulates, regrinds, powders and liquids in the configuration you wish.
MCHybrid 200: the best of dosing and blending in one system with real time throughput measurement
MCHybrid 200: the best of dosing and blending in one system with real time throughput measurement
MCHybrid 200: the best of dosing and blending in one system with real time throughput measurement
The MCHybrid 200* is a unique dosing concept that combines two technologies into one system: batch blending and in-line dosing.
The main materials or regrinds are mixed in an extreme compact gravimetric batch blender. Because the system only blends the main materials, the blending speed is high and therefore the batch blender remains small.
The additives are dosed gravimetrically in-line, directly on the throat of the injection molding machine or extruder.
By using these two blending and dosing technologies in one machine, you are able to control the main materials in any given ratio and at the same time dose additives at low percentages with unequalled accuracy.
The MCHybrid 200 is available for capacities up to 1,000 kg/h with 2-8 blending components and up to maximum 14 in-line dosing components.
If requested, the blender itself can also be used without the in-line dosing units. In that case the capacity and the accuracy will reduce compared to the MCHybrid concept.
* patent pending
Features MCHybrid 200
- Fully gravimetric
- 8” full color touch screen with user-friendly interface
- Able to store up to 1,000 recipes
- Capacity max. 1,000 kg/h
- 2-8 main components and max. 14 in-line additives
- Extremely compact
- Able to handle powders and liquids in one system
- Quick and easy change of additives
- Option of weighing mixing bin (real time throughput measurement)
- Industry 4.0 ready
Benefits MCHybrid 200
- Compact design
Because only the main components are blended gravimetrically, a high capacity can be achieved with a relatively small batch blender. - Different materials handled
The in-line dosing of the additives allows easy color change plus the option to use additives that cannot be handled with a regular batch blender, such as powders or liquids. - Extremely accurate
As the additives are dosed in-line, no segregation can take place which prevents color variations.
